Plank STAR
C034030100pSteel 240 YP
![OPTIMO-Plank-STAR-Steel-240YP-C034030100p-1.jpg](https://pcp.structpim.com/media/19333/optimo-plank-star-steel-240yp-c034030100p-1.jpg?anchor=center&mode=crop&rnd=132791661220000000&width=540&height=540,https://pcp.structpim.com/media/19333/optimo-plank-star-steel-240yp-c034030100p-1.jpg?anchor=center&mode=crop&rnd=132791661220000000&width=1080&height=1080 2x)
Specifications
- Slip resistance: R11 = 27° > slope > 19° acc. to DIN 51130
- Free area: 25-27 %
- Upward grip holes: Serrated dia. 21 mm
- Downward drainage holes: dia. 21 mm
- C-C grid: 50 x 40 mm
- Ball proof: 35 mm in accordance with EN ISO 14122-2
- Fire resistance: Critical temperature 550 °C
The product is also available in the material(s) below.
Downloads
-
Brochure
-
Datasheet
Standard dimensions
Get security and modern design at competitive prices with PcP OPTIMO.
Length (mm) | Width (mm) | Height (mm) | Mat. thickness (mm) | Finish | Availability | Item no. | |
---|---|---|---|---|---|---|---|
3000 | 150 | 34 | 3 | Mill finish | Stock item | C034030100p | |
3000 | 200 | 36 | 3 | Mill finish | On request | C034050100p | |
3000 | 250 | 34 | 3 | Mill finish | On request | C034040100p |
Item no. | |
---|---|
C034030100p | |
C034050100p | |
C034040100p |
