Trin ACHIL O2
F100796100Aluminium 3005-16 H66
![OPTIMO-Stufe-ACHIL-O2-Aluminium-3005-16-H66-F100796100-1.jpg](https://pcp.structpim.com/media/16499/optimo-stufe-achil-o2-aluminium-3005-16-h66-f100796100-1.jpg?anchor=center&mode=crop&rnd=132410637420000000&width=540&height=540, https://pcp.structpim.com/media/16499/optimo-stufe-achil-o2-aluminium-3005-16-h66-f100796100-1.jpg?anchor=center&mode=crop&rnd=132410637420000000&width=1080&height=1080 2x)
Specifikationer
- Skridsikkerhed: R13 = hældning >35° iht. DIN 51130
- Flange design: Achil [ b ]
- Friareal: 20-25 %
- Optrækshuller: ø9 mm
- Drænhuller: ø5 mm
- C-C grid: 25 x 25 mm
- Lastkapacitet: 1,5 kN / 100 x 100 mm iht. EN ISO 14122
Produktet findes også i andre materialer
Downloads
-
PDF Drawing
-
Datasheet
Standard dimensioner
Få maksimal sikkerhed kombineret med moderne design til konkurrencedygtige priser med PcP OPTIMO.
