Plank grating Plain
F972054200Stainless steel
Punched hole mesh gratings CUBE® Plain has a high stength-to-weight ratio which means that strength is maintained while weight is reduced. The greater the span, the lower is the weight – in relation to pressure-locked mesh gratings. CUBE® Plain mesh gratings are recommended in industries where hygiene and high air- or liquid flow are required.
![CUBE-Plank-Grating-C-CUBE-Plain-Stainless-steel-F972054200-1.jpg](https://pcp.structpim.com/media/17490/cube-plank-grating-c-cube-plain-stainless-steel-f972054200-1.jpg?anchor=center&mode=crop&rnd=132475811120000000&width=540&height=540,https://pcp.structpim.com/media/17490/cube-plank-grating-c-cube-plain-stainless-steel-f972054200-1.jpg?anchor=center&mode=crop&rnd=132475811120000000&width=1080&height=1080 2x)
![Cube Plank Grating Length Equals Span Direction](https://pcp.structpim.com/media/17683/cube-plank-grating-length-equals-span-direction.jpg?anchor=center&mode=crop&rnd=132503355970000000&width=540&height=540,https://pcp.structpim.com/media/17683/cube-plank-grating-length-equals-span-direction.jpg?anchor=center&mode=crop&rnd=132503355970000000&width=1080&height=1080 2x)
Specifications
- Free area: 50-56 %
- Downward drainage holes: 34x34 mm
- C-C grid: 43,5 x 43,5 mm
- Ball proof: 35 mm in accordance with BS 4592
The product is also available in the material(s) below.
Downloads
-
Video
-
Manual
-
Datasheet
- CUBE Plank grating Plain Stainless steel F972054200 1.pdf CUBE Plank grating Plain Stainless steel F972054200 1.pdf https://pcp.structpim.com/media/29412/cube-plank-grating-plain-stainless-steel-f9720542001.pdf
- CUBE Loading Chart Incl Weights.pdf CUBE Loading Chart Incl Weights.pdf https://pcp.structpim.com/media/24696/cube-loading-chart-incl-weights.pdf
