Plank grating Oyster
F972000300Steel 240 YP
Punched hole mesh gratings CUBE® has a high strength-to-weight ratio which means that strength is maintained while weight is reduced. The greater the span, the lower is the weight – in relation to pressure-locked mesh gratings. The CUBE® grating can be produced in three design variants depending on how much slip resistance is needed. CUBE® mesh gratings are recommended in most constructions and industries where high air- or liquid flow are required.
Specifications
- PTV guidelines: 36+ Low Slip Potential acc. to BS 7976
- Dry PTV average: 104 multi-directional acc. to BS 7976
- Wet PTV average: 70 multi-directional acc. to BS 7976
- Slip resistance: R13 = slope >35° acc. to DIN 51130
- Free area: 50-56 %
- Upward grip holes: Oyster - serrated dia 6,5 mm
- Downward drainage holes: 34x34 mm
- C-C grid: 43,5 x 43,5 mm
- Load capacity: 1,5 kN / 200 x 200 mm acc. to EN ISO 14122
- Ball proof: 35 mm in accordance with BS 4592
- Fire resistance: Critical temperature 550 °C
The product is also available in the material(s) below.
Designed for simplicity & efficiency
Cut-outs
You can easily make cut-outs on-site or let us help you customise your project
Load capacity
CUBE gratings, panels and stair treads comply to the European Industrial standard EN ISO 14122-2 for a concentrated load of min. 1.5 kN on 200x200 mm and to BS 4592 Part 0: 2006 +A1: 2012.
Accessories
We supply various fixing clamps and kick flats for platforms and walkways.
Slip-resistant
The CUBE® (oyster) punched hole mesh gratings are tested according to DIN 51130 and BS 7976-2 2002 for slip resistance.
Low weight
Punched hole mesh grating CUBE® has very high strength compared to the weight ratio due to the unique cold-formed design.
Quick and cost-efficient to install
The CUBE gratings and stair treads are quick and easy to install.
Ball proof
The CUBE® gratings are 35 mm ball-proof according to EN ISO 14122-2 and comply to BS 4592 Part 0: 2006 +A1: 2012
Downloads
-
PDF Drawing
-
Certificate
- CUBE OYSTER Steel 240YP Galvanised UKAS Physical Testing Report .pdf CUBE OYSTER Steel 240YP Galvanised UKAS Physical Testing Report.pdf https://pcp.structpim.com/media/17205/b-cube-oyster-steel-240yp-galvanised-ukas-physical-testing-report.pdf
- IFA DGUV Test Certificate 2019 22092 3210 - R13-V10 - CUBE Plank Grating OYSTER - Galvanised Steel .pdf IFA DGUV Test Certificate 2019 22092 3210 - R13-V10 - CUBE Plank Grating OYSTER - Galvanised Steel.pdf https://pcp.structpim.com/media/17686/ifa-2019-22092-3210-b-cube-r13-v10.pdf
-
Video
-
Manual
-
Datasheet
- CUBE Plank grating Oyster Steel 240 YP F972000300 1 .pdf CUBE Plank grating Oyster Steel 240 YP F972000300 1.pdf https://pcp.structpim.com/media/29387/cube-plank-grating-oyster-steel-240-yp-f9720003001.pdf
- CUBE Loading Chart Incl Weights .pdf CUBE Loading Chart Incl Weights.pdf https://pcp.structpim.com/media/24696/cube-loading-chart-incl-weights.pdf
Standard dimensions
Get security and modern design at competitive prices with PcP CUBE.
