CUBE Logo RGB Positive

Tread Oyster

F972400300

Steel 240 YP

CUBE® stair treads has a better strength-to-weight ratio than traditional mesh grating treads which means that strength is maintained while weight is reduced. CUBE® treads are manufactured with Oyster-surface between meshes for slip resistance. CUBE® stair treads are recommended in most constructions and industries especially where high air- and liquid flow are required.

Get a quote
Download product sheet

Specifications

  • PTV guidelines: 36+ Low Slip Potential acc. to BS 7976
  • Dry PTV average: 104 multi-directional acc. to BS 7976
  • Wet PTV average: 70 multi-directional acc. to BS 7976
  • Slip resistance: R13 = slope >35° acc. to DIN 51130
  • Free area: 50-56 %
  • Upward grip holes: Oyster - serrated dia 6,5 mm
  • Downward drainage holes: 34x34 mm
  • C-C grid: 43,5 x 43,5 mm
  • Load capacity: 1,5 kN / 100 x 100 mm acc. to EN ISO 14122
  • Fire resistance: Critical temperature 550 °C
Show all specifications

The product is also available in the material(s) below.


Downloads

Standard dimensions

Get security and modern design at competitive prices with PcP CUBE.

Length (mm) Width (mm) Height (mm) Thickness (mm) Finish Weight (kg) Availability Item no.
800 240 42 2 Mill Finish On request F180000100 STEP
800 240 42 2 Hot-dip galvanised EN 1461 4.48 Stock item F180000101 STEP
900 240 42 2 Hot-dip galvanised EN 1461 4.99 F180010101 STEP
1000 240 42 2 Mill Finish On request F180020100 STEP
1000 240 42 2 Hot-dip galvanised EN 1461 5.50 Stock item F180020101 STEP
1100 240 52 2 Hot-dip galvanised EN 1461 6.43 F180030101 STEP
1200 240 52 2 Hot-dip galvanised EN 1461 6.98 On request F180040101 STEP
800 270 47 2 Mill Finish On request F180100100 STEP
800 270 47 2 Hot-dip galvanised EN 1461 4.81 Stock item F180100101 STEP
900 270 47 2 Hot-dip galvanised EN 1461 5.35 F180110101 STEP
1000 270 47 2 Mill Finish On request F180120100 STEP
1000 270 47 2 Hot-dip galvanised EN 1461 5.89 Stock item F180120101 STEP
1100 270 52 2 Hot-dip galvanised EN 1461 6.85 F180130101 STEP
1200 270 52 2 Hot-dip galvanised EN 1461 7.42 Stock item F180140101 STEP
800 305 42 2 Hot-dip galvanised EN 1461 5.21 F180200101 STEP
900 305 42 2 Hot-dip galvanised EN 1461 5.79 F180210101 STEP
1000 305 42 2 Hot-dip galvanised EN 1461 6.37 Stock item F180220101 STEP
1100 305 57 2 Hot-dip galvanised EN 1461 7.49 On request F180230101 STEP
1200 305 57 2 Hot-dip galvanised EN 1461 7.98 Stock item F180240101 STEP
Item no.
F180000100 STEP
F180000101 STEP
F180010101 STEP
F180020100 STEP
F180020101 STEP
F180030101 STEP
F180040101 STEP
F180100100 STEP
F180100101 STEP
F180110101 STEP
F180120100 STEP
F180120101 STEP
F180130101 STEP
F180140101 STEP
F180200101 STEP
F180210101 STEP
F180220101 STEP
F180230101 STEP
F180240101 STEP
Show all variants

Tailormade solutions or standard products?

Interested in advice to find the right product or tailormade solution? Contact us and one of our experts will contact you.

Standard or bespoke open steel flooring solution?

Contact us!

Our experienced team of experts are ready to advice you about regulations and help you find the right product or solution for your project.
