Plank O2

C010000100p

Steel 240 YP

OPTIMO 02 planks offers higher slip resistance properties compared to mesh or bar grating products, which is of prime importance to designers, engineers and users worldwide. Type 02 planks are used in many applications where a high level of slip resistance is required. Standard planks are stocked therefore making the product readily available for either the client or PcP to fabricate into suitable panel sizes.

Get a quote
Download product sheet Download declaration of performance

Specifications

  • PTV guidelines: 36+ Low Slip Potential acc. to BS 7976
  • Dry PTV average: 66 multi-directional acc. to BS 7976
  • Wet PTV average: 50 multi-directional acc. to BS 7976
  • Slip resistance: R13 = slope >35° acc. to DIN 51130
  • Free area: 20-25 %
  • Upward grip holes: dia. 9 mm
  • Downward drainage holes: dia. 5 mm
  • C-C grid: 25 x 25 mm
  • Ball proof: 15, 20, 35 mm in accordance with BS 4592
  • Fire resistance: Critical temperature 550 °C
Show all specifications

The product is also available in the material(s) below.


Downloads

Standard dimensions

Get security and modern design at competitive prices with PcP OPTIMO.

Length (mm) Width (mm) Height (mm) Thickness (mm) Weight per meter (kg) Weight per m² (kg) Finish Availability Item no.
3000 100 45 2 Mill Finish Stock item C010100100p STEP
3000 100 45 2 Hot-dip galvanised EN 1461 C010100101p
3000 150 45 2 Mill Finish Stock item C010110100p STEP
3000 150 45 2 Hot-dip galvanised EN 1461 C010110101p
3000 200 45 2 Mill Finish Stock item C010120100p STEP
3000 200 45 2 Hot-dip galvanised EN 1461 On request C010120101p
3000 225 45 2 Mill Finish Stock item C010130100p STEP
3000 225 45 2 Hot-dip galvanised EN 1461 C010130101p
3000 250 45 2 Mill Finish Stock item C010140100p STEP
3000 250 45 2 Hot-dip galvanised EN 1461 On request C010140101p
3000 275 45 2 Mill Finish Stock item C010150100p STEP
3000 275 45 2 Hot-dip galvanised EN 1461 C010150101p
3000 300 45 2 Mill Finish Stock item C010160100p STEP
3000 300 45 2 Hot-dip galvanised EN 1461 On request C010160101p
6000 50 33 2 1.46 Mill Finish Stock item C010000100p STEP
6000 50 33 2 31.8 Hot-dip galvanised EN 1461 On request C010000101p
6000 62 33 2 1.61 Mill Finish Stock item C010010100p STEP
6000 62 33 2 28.5 Hot-dip galvanised EN 1461 C010010101p
6000 75 33 2 1.78 Mill Finish Stock item C010020100p STEP
6000 75 33 2 26.2 Hot-dip galvanised EN 1461 C010020101p
6000 87 33 2 1.93 Mill Finish Stock item C010030100p STEP
6000 87 33 2 24.6 Hot-dip galvanised EN 1461 C010030101p
6000 100 33 2 2.1 Mill Finish Stock item C010040100p STEP
6000 100 33 2 23.4 Hot-dip galvanised EN 1461 On request C010040101p
6000 112 33 2 2.25 Mill Finish Stock item C010050100p STEP
6000 112 33 2 22.5 Hot-dip galvanised EN 1461 On request C010050101p
6000 125 33 2 2.42 Mill Finish Stock item C010060100p STEP
6000 125 33 2 21.7 Hot-dip galvanised EN 1461 C010060101p
6000 137 33 2 2.57 Mill Finish Stock item C010070100p STEP
6000 137 33 2 21.1 Hot-dip galvanised EN 1461 C010070101p
6000 150 33 2 2.74 Mill Finish Stock item C010080100p STEP
6000 150 33 2 20.5 Hot-dip galvanised EN 1461 On request C010080101p
6000 200 33 2 3.38 Mill Finish Stock item C010090100p STEP
6000 200 33 2 19.1 Hot-dip galvanised EN 1461 C010090101p
Item no.
C010100100p STEP
C010100101p
C010110100p STEP
C010110101p
C010120100p STEP
C010120101p
C010130100p STEP
C010130101p
C010140100p STEP
C010140101p
C010150100p STEP
C010150101p
C010160100p STEP
C010160101p
C010000100p STEP
C010000101p
C010010100p STEP
C010010101p
C010020100p STEP
C010020101p
C010030100p STEP
C010030101p
C010040100p STEP
C010040101p
C010050100p STEP
C010050101p
C010060100p STEP
C010060101p
C010070100p STEP
C010070101p
C010080100p STEP
C010080101p
C010090100p STEP
C010090101p
Show all variants
