Tread ACHIL O2

F100000101

Steel 240 YP

Classified in the highest anti-slip class R13 according to DIN 51130. Upwards punched holes and downwards drain holes ensure drainage of liquids so that the surface is dry and non-slip. The rolled flanges provides the stair tread a high load capacity, while protecting footwear and sharp edges are avoided. The tread comes with bolt holes in end pieces for mounting on the stringers.

Get a quote
Download product sheet

Specifications

  • PTV guidelines: 36+ Low Slip Potential acc. to BS 7976
  • Dry PTV average: 66 multi-directional acc. to BS 7976
  • Wet PTV average: 50 multi-directional acc. to BS 7976
  • Slip resistance: R13 = slope >35° acc. to DIN 51130
  • Free area: 20-25 %
  • Upward grip holes: dia. 9 mm
  • Downward drainage holes: dia. 5 mm
  • C-C grid: 25 x 25 mm
  • Flange design: Achil [ b ]
  • Fire resistance: Critical temperature 550 °C
  • Designed in accordance with BS 4592
  • EN1991EurocodeLoad 3 kN / 100x100mm
Show all specifications

Downloads

Standard dimensions

Get security and modern design at competitive prices with PcP OPTIMO.

Length (mm) Width (mm) Height (mm) Thickness (mm) Finish Weight (kg) Availability Item no.
400 150 45 2 Hot-dip galvanised EN 1461 3.20 F100000101 STEP
500 150 45 2 Hot-dip galvanised EN 1461 3.20 Stock item F100010101 STEP
600 150 45 2 Hot-dip galvanised EN 1461 3.20 Stock item F100020101 STEP
700 150 45 2 Mill Finish 3.70 On request F100030100 STEP
700 150 45 2 Hot-dip galvanised EN 1461 3.70 On request F100030101 STEP
800 150 45 2 Hot-dip galvanised EN 1461 4.20 On request F100040101 STEP
900 150 45 2 Hot-dip galvanised EN 1461 4.70 F100050101 STEP
1000 150 45 2 Hot-dip galvanised EN 1461 5.10 On request F100060101 STEP
1100 150 58 2 Hot-dip galvanised EN 1461 5.80 F100070101 STEP
1200 150 58 2 Hot-dip galvanised EN 1461 6.30 F100080101 STEP
1300 150 58 2 Hot-dip galvanised EN 1461 6.80 F100090101 STEP
1500 150 58 2 Hot-dip galvanised EN 1461 7.90 F100100101 STEP
400 200 45 2 Hot-dip galvanised EN 1461 3.70 F100110101 STEP
500 200 45 2 Hot-dip galvanised EN 1461 3.70 On request F100120101 STEP
600 200 45 2 Hot-dip galvanised EN 1461 3.70 Stock item F100130101 STEP
700 200 45 2 Hot-dip galvanised EN 1461 4.20 F100140101 STEP
800 200 45 2 Hot-dip galvanised EN 1461 4.80 On request F100150101 STEP
900 200 45 2 Hot-dip galvanised EN 1461 5.30 F100160101 STEP
1000 200 45 2 Hot-dip galvanised EN 1461 5.90 F100170101 STEP
1100 200 58 2 Hot-dip galvanised EN 1461 7.10 F100180101 STEP
1200 200 58 2 Hot-dip galvanised EN 1461 7.70 Stock item F100190101 STEP
1500 200 58 2 Hot-dip galvanised EN 1461 9.40 F100200101 STEP
400 225 45 2 Hot-dip galvanised EN 1461 3.90 F100210101 STEP
500 225 45 2 Hot-dip galvanised EN 1461 3.90 On request F100220101 STEP
600 225 45 2 Mill Finish 3.90 On request F100230100 STEP
600 225 45 2 Hot-dip galvanised EN 1461 3.90 Stock item F100230101 STEP
700 225 45 2 Hot-dip galvanised EN 1461 4.50 On request F100240101 STEP
800 225 45 2 Hot-dip galvanised EN 1461 5.10 On request F100250101 STEP
900 225 45 2 Hot-dip galvanised EN 1461 5.70 F100260101 STEP
1000 225 45 2 Hot-dip galvanised EN 1461 6.20 F100270101 STEP
1100 225 58 2 Hot-dip galvanised EN 1461 7.50 F100280101 STEP
1200 225 58 2 Hot-dip galvanised EN 1461 8.10 F100290101 STEP
1500 225 58 2 Hot-dip galvanised EN 1461 10.00 F100300101 STEP
500 250 45 2 Hot-dip galvanised EN 1461 4.20 On request F100310101 STEP
600 250 45 2 Hot-dip galvanised EN 1461 4.20 Stock item F100320101 STEP
700 250 45 2 Mill Finish 4.80 On request F100330100 STEP
700 250 45 2 Hot-dip galvanised EN 1461 4.80 On request F100330101 STEP
800 250 45 2 Hot-dip galvanised EN 1461 5.40 Stock item F100340101 STEP
900 250 45 2 Hot-dip galvanised EN 1461 6.00 Stock item F100350101 STEP
1000 250 45 2 Hot-dip galvanised EN 1461 6.60 Stock item F100360101 STEP
1100 250 58 2 Hot-dip galvanised EN 1461 7.90 F100370101 STEP
1200 250 58 2 Hot-dip galvanised EN 1461 8.20 Stock item F100380101 STEP
1300 250 58 2 Hot-dip galvanised EN 1461 8.60 F100390101 STEP
1500 250 58 2 Hot-dip galvanised EN 1461 10.50 F100400101 STEP
600 275 45 2 Hot-dip galvanised EN 1461 4.40 Stock item F100410101 STEP
700 275 45 2 Mill Finish 5.00 On request F100420100 STEP
700 275 45 2 Hot-dip galvanised EN 1461 5.00 On request F100420101 STEP
800 275 45 2 Mill Finish 5.70 On request F100430100 STEP
800 275 45 2 Hot-dip galvanised EN 1461 5.70 Stock item F100430101 STEP
900 275 45 2 Mill Finish 6.30 On request F100440100 STEP
900 275 45 2 Hot-dip galvanised EN 1461 6.30 Stock item F100440101 STEP
1000 275 45 2 Hot-dip galvanised EN 1461 7.00 Stock item F100450101 STEP
1100 275 58 2 Hot-dip galvanised EN 1461 8.30 Stock item F100460101 STEP
1200 275 58 2 Hot-dip galvanised EN 1461 9.00 Stock item F100470101 STEP
1300 275 58 2 Hot-dip galvanised EN 1461 9.40 F100480101 STEP
1500 275 58 2 Hot-dip galvanised EN 1461 11.10 F100490101 STEP
600 300 45 2 Hot-dip galvanised EN 1461 4.60 On request F100500101 STEP
700 300 45 2 Hot-dip galvanised EN 1461 5.30 F100510101 STEP
800 300 45 2 Mill Finish 6.00 On request F100520100 STEP
800 300 45 2 Hot-dip galvanised EN 1461 6.00 On request F100520101 STEP
900 300 45 2 Mill Finish 6.70 On request F100530100 STEP
900 300 45 2 Hot-dip galvanised EN 1461 6.70 Stock item F100530101 STEP
1000 300 45 2 Hot-dip galvanised EN 1461 7.40 Stock item F100540101 STEP
1100 300 58 2 Hot-dip galvanised EN 1461 8.70 F100550101 STEP
1200 300 58 2 Hot-dip galvanised EN 1461 9.40 On request F100560101 STEP
1300 300 58 2 Mill Finish 9.90 On request F100570100 STEP
1300 300 58 2 Hot-dip galvanised EN 1461 9.90 F100570101 STEP
1500 300 58 2 Hot-dip galvanised EN 1461 11.60 On request F100580101 STEP
