Tread Plank ACHIL O2

C000700100

Steel 240 YP

Optimo O2 Achil stair tread manufactured from Carbon Steel and galvanised to BS EN 1461: 2009, readily available stock in various widths and lengths to suit your application. The O2 Achil tread is the perfect choice for Industrial, commercial & private staircases. With loading's designed in accordance with BS4592  and excellent drainage / slip resistance.



Get a quote
Download product sheet

Specifications

  • PTV guidelines: 36+ Low Slip Potential acc. to BS 7976
  • Dry PTV average: 66 multi-directional acc. to BS 7976
  • Wet PTV average: 50 multi-directional acc. to BS 7976
  • Slip resistance: R13 = slope >35° acc. to DIN 51130
  • Free area: 20-25 %
  • Upward grip holes: dia. 9 mm
  • Downward drainage holes: dia. 5 mm
  • C-C grid: 25 x 25 mm
  • Flange design: Achil [ b ]
  • Fire resistance: Critical temperature 550 °C
  • EN1991EurocodeLoad 3 kN / 100x100mm
Show all specifications

Based on the standard O2 pattern with 9mm diameter raised holes & 5mm diameter depressed holes. The O2 "Achil" benefits from a rolled front/rear edge that both increases strength and protects the Achilles tendon by preventing footwear from catching in use. Type "O2 Achil" is available in Galvanised Steel standard stock sizes.

  • Material Carbon Steel 240Yp / Galvanised to BS EN 1461: 2009
  • High slip resistance / Drainage
  • Available stock / Bespoke sizes
  • Data sheet and product certificates available upon request.

Downloads

Standard dimensions

Get security and modern design at competitive prices with PcP OPTIMO.

Length (mm) Width (mm) Height (mm) Thickness (mm) Finish Item no.
600 150 45 2 Mill Finish C000700100 STEP
700 150 45 2 Mill Finish C000710100 STEP
800 150 45 2 Mill Finish C000720100 STEP
900 150 45 2 Mill Finish C000730100 STEP
1000 150 45 2 Mill Finish C000740100 STEP
1100 150 58 2 Mill Finish C001250100 STEP
1200 150 58 2 Mill Finish C001260100 STEP
1300 150 58 2 Mill Finish C001270100
1500 150 58 2 Mill Finish C001280100 STEP
600 200 45 2 Mill Finish C000750100 STEP
700 200 45 2 Mill Finish C000760100 STEP
800 200 45 2 Mill Finish C000770100 STEP
900 200 45 2 Mill Finish C000780100 STEP
1000 200 45 2 Mill Finish C000790100 STEP
1100 200 58 2 Mill Finish C001170100
1200 200 58 2 Mill Finish C000800100 STEP
1300 200 58 2 Mill Finish C000810100 STEP
1500 200 58 2 Mill Finish C000820100 STEP
600 225 45 2 Mill Finish C000830100 STEP
700 225 45 2 Mill Finish C000840100
800 225 45 2 Mill Finish C000850100 STEP
900 225 45 2 Mill Finish C000860100 STEP
1000 225 45 2 Mill Finish C000870100 STEP
1100 225 58 2 Mill Finish C001180100 STEP
1200 225 58 2 Mill Finish C000880100 STEP
1300 225 58 2 Mill Finish C000890100
1500 225 58 2 Mill Finish C000900100 STEP
600 250 45 2 Mill Finish C000910100
700 250 45 2 Mill Finish C000920100 STEP
800 250 45 2 Mill Finish C000930100 STEP
900 250 45 2 Mill Finish C000940100 STEP
1000 250 45 2 Mill Finish C000950100 STEP
1100 250 58 2 Mill Finish C001190100 STEP
1200 250 58 2 Mill Finish C000960100 STEP
1300 250 58 2 Mill Finish C000970100 STEP
1500 250 58 2 Mill Finish C000980100 STEP
600 275 45 2 Mill Finish C000990100 STEP
700 275 45 2 Mill Finish C001000100
800 275 45 2 Mill Finish C001010100 STEP
900 275 45 2 Mill Finish C001020100 STEP
1000 275 45 2 Mill Finish C001030100 STEP
1100 275 58 2 Mill Finish C001200100 STEP
1200 275 58 2 Mill Finish C001040100 STEP
1300 275 58 2 Mill Finish C001050100 STEP
1500 275 58 2 Mill Finish C001060100 STEP
600 300 45 2 Mill Finish C001070100 STEP
700 300 45 2 Mill Finish C001080100
800 300 45 2 Mill Finish C001090100 STEP
900 300 45 2 Mill Finish C001100100 STEP
1000 300 45 2 Mill Finish C001110100 STEP
1100 300 58 2 Mill Finish C001210100 STEP
1200 300 58 2 Mill Finish C001120100 STEP
1300 300 58 2 Mill Finish C001130100 STEP
1500 300 58 2 Mill Finish C001140100 STEP
